Technical Specifications
SAODMCIP2001
Salient Features
Power Required
380-440v/3 Ph/6kW
Compressor Auto Cut Off System
Air Required
NA
Flow Switch For Compressor Protection
Production Capacity
300 LPH
Preventive & Timer Circuit For Compressor
Approx. Dim. (LxWxH Mtrs.)
--
Single Unit Only (Indoor)
Approx. Weight (Kgs)
1300
Control Panel Non Flameproof
Manpower Required
1
High Level Low Level Trip Pre Fitted
Make Of Electrical Components
ABB/Bitzer
Temperature Gauges
Make Of Pneumatic Components
NA
Price
Make Of Electronic Components
Siemens/Schneider
Contact Us
Make Of Valves & Fittings
Cipriani/Inoxpa
Add Ons (For Pricing Contact Us)
Contact Parts MOC
SS 304L
Spare Kit (Recommended Add On)
Non Contact Parts MOC
SS 304
Copper Piping, Gasing & Testing (Req.)
No. Of Filter Plates
15
Integration With Auto Control Panel
Pre Fitted Paper Pad Filter Size
5 Microns
Change To PP Candle Type Filter
Inlet & Outlet Liquid Temp. Max.
20 & -4 Degrees C
--
Accepted Ambient Temp. Max.
22 Degrees C
--
Inlet & Outlet Size (Inch)
1.5 & 1
--
